Kobewel 500A MIG/MAG Arc Welding Machine KMD Series KMD-502
(With Separate Wire Feeder)
Specification
- Welding Range 40 - 500 A
- Main Frequency 60 Hz
- Load Voltage 16 - 39 V
- Main Fuse (Slow-Blow) 35 A
- No Load Voltage 49 V
- Max Power Consumption
- Voltage Settings 4 x 10
- 380 V 23 kVA
- Duty Cycle at Max Current 60%
- Power Factor 0.96
- Welding Current at 100%
- Insulation Class H
- Duty Cycle 390 A
- Cooling Type F
- Weldable Steel Wire 0.8 - 2.4 mm Dimension
- Noise Emission < 75 dB (A)
- Weldable Aluminum Wire 0.9 - 2.4 mm
- Wire Feeder Dimension 550 x 242 x 410 mm
- Dimension 950 x 390 x 750 mm
- Wire Feed Rate 0.5 - 20 m/min
- Machine Weight 150 Kg
- Main Voltage 3 - 380 V
- Wire Feeder Weight 21 Kg
Standard Accessories
- 1 set MIG Torch #SOD (3 m Long) + 5 pcs Contact Tip
- 1 pc Earth Clamp+ Cable (50 mm2 ) (3 m Long)
- 1 pc C02 Regulator with Heater (220 V)
- 1 pc Air Hose (3 m Long)
