ADELINO PERIPHERAL PUMP
Brand : Adelino
Application Limits
◎ Suction head up to 8m
◎ Liquid temperature up to +40℃
◎ Ambient temperature up to +40℃
◎ Max. Working pressure: 6bar
◎ Voltage fluctuation should not exceed 10% of rated value.
◎ pH: 6.5 to 8.5
Application Fields
◎ Suitable for transferring water without abrasive particles or other liquid whose properties are similar to water.
◎ Widely used in garden irrigation, vegetable greenhouse water supply, breeding industry water supply and drainage, various corollary equipment, etc.
Basic Configuration
◎ Pump body: cast iron
◎ Impellers: brass
◎ Shaft: 45 # Steel
◎Mechanical sealing: ceramic / graphite / NBR rubber
◎Motor: two asynchronous motors, copper coils, built in thermal protection, all closed fan-cooled, continuous operation
◎Protection: IP44
◎Insulation class: B
Note : See individual Product Specification.
| Model No. | Rated Power (HP) | Max Head (m) | Max. Flow (m3/h) | Head Range (m) | Max Suction (m) | Rate Current |
|---|---|---|---|---|---|---|
| AP37K/QB60K | 0.5 | 40 | 2.4 | 1.5 to 30 | 8 | 220v, 60Hz, Single Phase |
| AP55 | 0.75 | 48 | 3 | 1.5 to 44 | 8 | 220v, 60Hz, Single Phase |
| AP75/QB0 | 1 | 60 | 3.6 | 2.5 to 53 | N/A | 220v, 60Hz, Single Phase |
