Sharkpro 1/2HP or 1HP Jet Pump with Pressure Tank (set)

Sharkpro 1/2HP or 1HP Jet Pump with Pressure Tank (set)

by Sharkpro
₱7,000.00
Motor (Hp)
Size of Tank
Brand of Tank

Sharkpro 1HP Jet Pump with Bladder /Pressure Tank  , Pressure Switch and Gauge (set)

Specifications :

Waterpump

1/2Hp

  • Model : QB60
  • Power : 1/2Hp
  • Voltage : 220v
  • Q. Max : 35lpm
  • Max. Head : 35m

or

1Hp

  • Model : JET100B
  • Power : 1HP
  • Max. Head : 45m
  • Q. Max : 80l/min.
  • 1"x1"
  • Max. Suction : 9m

Pressure Tank

  • Tank Size : 12Gals./21Gals./42Gals./82Gals.
  • Brand of Tank : Extreme or Bestank
  • Material : Stainless Steel
  • Thickness : Gauge 16
  • Steel Grade : 304
  • Pressure Range : 20 to 40Psi

Pressure Switch

  • Brand : Square D
  • Class : 9013
  • Type : FSG-2
  • Pressure Range : 20 to 40psi
  • Base : Metal

Pressure Gauge

  • Brand : Ametek
  • Pressure Range : 0 to 100Psi
  • Wetted Material : Brass
  • Case Material : Steel Painted Black
  • Size : 2" or 50mm
  • Connection Size : 1/4" NPT
  • Mounting Location : Center Back Mount
  • Application : House, Townhouse, Building, Warehouse, etc.

Note :

  1. This is sold as set.
  2. It includes (Waterpump, Pressure Tank, Switch and Gauge & some GI fittings attached to it as show shown above). NO fittings included for 42Gals. and 82Gals.
  3. Drain Plug at the bottom of the Pressure Tank NOT included.
  4. You will received this item assembled already.

  5. For other configuration like 1Hp waterpump with 42Gals./82 Gals. Pressure Tank can be done but has to be bought one by one and NOT as set/assembled.

    6. Message us for more inquiries.
