Dayuan Swimming Pool Pump
Technical Data
- Max. Head : 18m
- Max. Flow: 26.5 m3h
- Max. Suction: 3m
Features:
-
All copper-winding motor
-
Docking Rotor
-
All Plastic wetted parts
-
Ambient temperature: 5°C-50°C
- Liquid Temperature: 4°C-50°C
- Liquid pH: 6.5-8.5
- Max. particle diameter: 0.2mm
- Power: 230V/50Hz
Applications:
- Circulation & filtration of various small swimming pools
- Filtration of marine water and Light-dirty water with solids in suspension
- Water circulating and fountains in various urban amusement attractions
- Used for water circulation of air source heat pump units
Specifications:
- Motor 100% Copper Winding
- Single Phase Motor
| Pump Type | Connector | Power | Voltage | Max. Head | Max. Flow | Max Suction |
|---|---|---|---|---|---|---|
| Inch | w | v | m3/h | L/min | m | |
| DSWm750 | 2" | 750 | 230 | 13 | 18 | 3 |
| DSWm1100 | 2" | 1100 | 230 | 17 | 21 | 3 |
| DSWm1500 | 2" | 1500 | 230 | 18 | 23.5 | 3 |
